Super Duplex 4501 Material | UNS S32760 Specification and Composition

UNS S32760 and WNR 1.4501 Alloy Supplier in India at Lowest Price

Offering Zeron 100 Material in Wide Range of Sizes, Refer Specification

Super Duplex 4501 Specification

Super Duplex 4501 Flanges

SCH: Sch 5 to XXS
NPS: 1/2" to 48"

UNS S32760 Pipe Fittings

Welded Fittings:1/2" - 48"
Seamless Fittings:1/2" - 10″

WNR 1.4501 Pipe and Tube

Pipe OD: 6.00 to 250 mm
Tube OD: 9.525 to 25.4 mm

Zeron 100 Sheet and Plate

Plate: 4.5 to 100 mm thik
Sheet: 0.02 to 4.0 mm thik

Duplex 4501 Fasteners

Metric sizes: M3 to M56
Imperial Sizes : 3/6" to 2"

SDSS 4501 Round Bar

Length: 1- 6 meter
Diameter: 3 to 800mm

Super Duplex S32760 Tube Fittings

Sizes: 3 to 50mm
Forms : Cap, Plug, Tee, Cross, Elbow

Super Duplex 4501 Forged Fittings

Sizes: 1/8" to 4" NB
Class: 2000 to 9000 LBS

Applications of Duplex 4501

Pharmaceutical, Mining
Desalination
Oil and gas, Chemical
Pulp and paper
Power generation

Features of UNS S32760

Superior resistance to sulfuric acid in many different concentrations
Resistance to pitting and crevice corrosion
Minimum Yield Strength of 80,000 psi
More cost-effective than most nickel based alloys

Stockists of Duplex 4501 Flat and Long products in Mumbai For Various Application

Industry Names: Zeron 100, Super Duplex 4501, Duplex 4501, Super Duplex S32760, 25Cr Super Duplex.
Specifications: UNS S32760, WNR 1.4501, F55.
Applications: Oil and gas, Pulp and paper, Power generation, Chemical, Pharmaceutical, Mining, Desalination.
Features: Resistance to pitting and crevice corrosion, Superior resistance to sulfuric acid in many different concentrations, Stress corrosion cracking resistance, Minimum Yield Strength of 80,000 psi, More cost-effective than most nickel based alloys, Outstanding machinability.

Zeron 100 HS Code

Material	HS code
Zeron 100	730431

Zeron 100 with UNS S32760 is a super duplex stainless steel containing 25% Cr, 4% Mo, and 7% Ni with addition of Copper and Tungsten, resulting excellent corrosion resistance, designed for acid leach mining applications and other industries where sulfuric acid is encountered.

Super Duplex 4501 also known as Super Duplex S32760 is a super duplex stainless steel with a composition of 25% chromium, 3.6% molybdenum, 1.0 copper and 0.7% tungsten for excellent pitting resistance to various chlorides and organics acids. Super Duplex S32760 has excellent corrosion resistance combined with high strength. Zeron 100 is made to meet a minimum pitting resistance equivalent (PREn) value of 40. The ferritic structure and alloy additions, such as nitrogen provide yield strengths that are twice that of 300 series stainless steels.

The addition of Copper in Super Duplex S32760 provides good resistance to sulfuric acid, Thus, Super Duplex 4501 is used in acid leach mining applications, steel pickling and other industries where sulfuric acid is encountered. Super Duplex UNS S32760 is among the most common super duplex grade in the market. Zeron 100 is a super duplex stainless steel especially designed for service in aggressive chloride-containing environments and has additions of W and Cu compared to UNS S32750. Duplex 4501 has very good resistance to localized corrosion and stress corrosion cracking in combination with high mechanical strength.

25Cr Super Duplex is a super duplex stainless steel supplied in the hot worked and solution annealed condition. As a super duplex stainless steel, it combines the desirable aspects of both austenitic and ferritic grades. Duplex 4501 provides higher strength than both austenitic and 22% Cr duplex stainless steels, and is listed in NACE MR 0175 for sour service and ASME for pressure vessel applications.

Super Duplex S32760 Supplier Siddhagiri Metals and Tubes offers high quality 904L Stainless Steel in forms like Super Duplex Pipe, Super Duplex Sheet Plate, Super Duplex Wire Mesh, Super Duplex Wire. Siddhagiri Metals and Tubes Specializes in grades like Super Duplex 4501, Super Duplex S32760, Duplex 4501, Super Duplex Stainless Steel, UNS S32760, WNR 1.4501.

For more information on Super Duplex S32760 please contact us.

Super Duplex 4501 | Zeron 100 | Super Duplex S32760 | Duplex 4501 | UNS S32760 | WNR 1.4501
Super Duplex 4501, is a nickel-iron-chromium austenitic alloy that was developed for maximum resistance to acid attack, specifically sulfuric acid. Siddhagiri Metals and Tubes Supplies high quality Zeron 100 with UNS S32760 and WNR 1.4501.

Know More About SDSS 4501 Chemical Composition and Mechanical Properties

SDSS 4501 Chemical Composition and Mechanical Properties

Chemical Properties

	C	P	Mn	N	S	Si	Cr	Ni	Mo	Cu	W	PRE*
MIN	-	-	-	0.200	-	-	24.000	6.000	3.000	0.500	0.500	40.000
MAX	0.030	0.030	1.000	0.300	0.010	1.000	26.000	8.000	4.000	1.000	1.000

Mechanical Properties

	Yield Strength 0.2% Proof (MPa)	Tensile strength (MPa)	Elongation (% in 50mm)	Hardness (HB)
MIN	550	750	25.00
MAX				270

Physical Properties

	Units	20°C	100°C	200°C	300°C
Density	g/cm³	7.8
Density	lb/in³	0.28
Modulus of elasticity	GPa	200	194	186	180
Modulus of elasticity	psi x 10-6	29
Poissons ratio		0.3
Linear expansion (RT ➞ T)°C	x 10-6/°C	-	13	13.5	14
Thermal conductivity	W/m°C	15	16	17	18
	Btu/h ft°F	8.7
Thermal capacity	J/kg°C	500	530	560	590
Electric resistivity	µΩm	0.8	0.85	0.9	1

Find Super Duplex S32760 Equivalent Standard Before Buying The Material

Super Duplex S32760 Equivalent Standard

Grade	North America	Forging Grade	France	Germany	European	Other Names
Super Duplex 4501	UNS S32760	F55	AFNOR Z3CND25.06Az	WNR/DIN 1.4501	EURONORM X2CrNiMoCuWN25.7.4	Super Duplex S32760 / Zeron 100
