 Incoloy 825 Forged Fittings Manufacturer

Siddhagiri Metals and Tubes is a well known supplier and manufacturer of Incoloy 825 Forged Fittings. We supply a comprehensive range in ASTM B564 UNS N08825 Fittings, catering for the demands of a wide range of industries.
Other Names: ASTM B564 UNS N08825, Incoloy Fittings, Incoloy 825 Fittings, Incoloy Forged Fittings, ASTM B564 Fittings
Material: Incoloy 825
Brand: Siddhagiri Metals and Tubes
Manufacturer: Siddhagiri Metals and Tubes
Rating: 4.5/5 based on 90 customer reviews

ASTM B564 UNS N08825 • Incoloy Fittings • Incoloy Outlets • Incoloy Socket weld Fittings • Incoloy Threaded Fittings • ASTM B564 Fittings

Incoloy 825 Forged Fittings supplied by Siddhagiri Metals and Tubes is of high quality and corrosion resistant. We are a specialist in ASTM B564 UNS N08825 Fittings. The ASTM B564 Fittings, we supply includes a complete range of alloys that demonstrate high strength and high resistance to heat and corrosion in even the most extreme conditions. We have supplied to almost 70 countries worldwide.

Siddhagiri Metals and Tubes is a specialist of Incoloy Socket weld Fittings, Incoloy Threaded Fittings and Incoloy Outlets. We have a varied stock of Incoloy forgings and fittings

Socket Weld Elbow & Threaded Elbow — Socket Weld Elbow and Threaded Elbow Fitting is a fitting installed between two lengths of pipe or tubing allowing a change of direction, usually 180°, 90° or 45°. Incoloy Elbows are available in short and long radius types. The ends can be machined for screwed or socketed. When the two ends differ in size, it is called a Reducing Elbow or Reducer Elbow.

Socket Weld Tee & Threaded Tee — We supply SocketWeld Tee & Threaded Tee for use in industrial applications. Incoloy Tees are used to combine or split a fluid flow. The most common Socket Weld and Threaded Tees have the same inlet and outlet sizes.

Socket Weld Cross & Threaded Cross — Crosses are used as junctions in piping systems. Manufactured as per ASME B16.11 BS3799 dimension standards Incoloy crosses are available in all size ranges.

Socket Weld Plug & Threaded Plugs — Plugs are similar to Caps in the application. Some forms of Threaded Plugs supplied by us are Square Head plug, Round Head plug and Hex Head plug.

Socket Weld Couplings & Threaded Couplings — Couplings fitting are used to connects two pipes to each other. Reducing Couplings can be used if the material and size of the pipe differ.

Socket Weld Cap & Threaded Caps — Cap are used to seal the end of the pipe to stop the flow of liquid or gas flowing through the pipe. Similar to plugs, Caps are available as Socket Weld Caps and Threaded Caps.

Socket Weld Union & Threaded Union — Unions Fittings are similar to Couplings. Manufactured as per ASME B16.11, ANSI B16.9, BS 3799 Standards. Socket weld Union and Threaded Unions are available in stock.

Threaded Pipe Nipple Fittings — Threaded Nipples are used to connect two ends of fittings. Pipe Nipples are also known as Barrel Nipples.

Incoloy 825 Outlets — Branch type connections in a piping system are known as outlets. Our inventory of Branch Outlets includes Buttweld Outlet, Elbow Outlet, Lateral Outlet, Nipple Outlet available in BW/SW/NPT and other outlets such as Insert Branch Outlets, Flange Buttweld Outlet, Flange Nipple, Outlet commonly used in oil, gas, power and nuclear industry pipe systems.

Siddhagiri Metals and Tubes manufactures High-quality Incoloy Fittings conforming to international standards and specifications ASME B16.11, ANSI B16.9, BS 3799. With over 30 years experience providing fitting solutions for a wide variety of applications, our products are guaranteed to be dependable and help you achieve the highest degree of efficiency. The size range of Socket Weld Fittings are 1/8" NB to 4" NB in Class 3000lbs and 6000lbs, Threaded Fittings are 1/8" NB to 4" NB in Class 2000lbs, 3000lbs and 6000lbs and that of Outlets are 1/2" to 14". We have exported Forged Fittings in many countries namely UAE, USA, South Africa, Australia, Japan, Europe, Qatar, Russia, Brazil, Chile, Thailand, Malaysia, Indonesia, Norway, Uk, Turkey, etc.

  • Forged Fittings Specification: ASTM B564 UNS N08825, ASME SB564 UNS N08825 & EN 2.4858
  • Dimension Standard: ASME B16.11, ANSI B16.9, BS 3799
  • Socket Weld Fittings Size Range: 1/8" NB to 4" NB in Class 3000lbs & 6000lbs
  • Threaded Fittings Size Range: 1/8" NB to 4" NB in Class 2000lbs, 3000lbs & 6000lbs
  • Outlets Size Range: 1/2" to 14"
  • Type: Forged Fittings, Threaded Fittings, Socket-weld Fittings, Outlets
  • Forms: Incoloy 825 Socket Weld Elbow, Incoloy 825 Threaded Elbow, Incoloy 825 Socket Weld Tee, Incoloy 825 Threaded Tee, Incoloy 825 Socket Weld Cross, Incoloy 825 Threaded Cross, Incoloy 825 Socket Weld Coupling, Incoloy 825 Threaded Coupling, Incoloy 825 Socket Weld Cap, Incoloy 825 Socket Weld Hex Nipple, Incoloy 825 Threaded Hex Nipple, Incoloy 825 Socket Weld Boss, Incoloy 825 Threaded Boss, Incoloy 825 Socket Weld Union, Incoloy 825 Threaded Union, Incoloy 825 Threaded Cap, Incoloy 825 Socket Weld Plug, Incoloy 825 Threaded Plug, Incoloy 825 Socket Weld Bushing, Incoloy 825 Threaded Bushing, Incoloy 825 Sockolet, Incoloy 825 Sockolet, Incoloy 825 Weldolet, Incoloy 825 Threadolet, Incoloy 825 Coupling, Incoloy 825 Boss, Buttweld Outlet(O’Let) - BW/SW/NPT, Incoloy 825 Elbow Outlet- BW/SW/NPT, Incoloy 825 Lateral Outlet- BW/SW/NPT, Incoloy 825 Nipple Outlet- BW/SW/NPT, Incoloy 825 Insert Branch Outlet, Incoloy 825 Flange Outlet, Incoloy 825 Flange Outlet
  • Origin: Indian Origin, European Origin, Japanese Origin
  • Testing and Documents: Mill Test Certificates, EN 10204 3.1, Chemical Reports, Mechanical Reports, Destructive Test Report, Non Destructive Test Reports, PMI Test Reports, Visual Inspection Reports, Third Party Inspection Reports, NABL Approved Lab Reports
  • Packing: Packed in Wooden Boxes, Bubble wraps, Steel Strips Bundled, or as per Customers Requests

Incoloy 825 Alloy Forged Fitting Sizes in Stock

Forms of Forged Fittings Type of Forged Fittings Size Range Dimension Standards
Incoloy 90 Degree Elbow Socket Weld Fittings 1/8" NB to 4" NB in Class 3000 & 6000 ASME B16.11, BS3799
Incoloy 45 Degree Elbow
Incoloy Cross
Incoloy Tee
Incoloy Cross
Incoloy Coupling
Incoloy Half Coupling
Incoloy Cap
Incoloy Welding Boss
Forms of Forged Fittings Type of Forged Fittings Size Range Dimension Standards
Incoloy 90 Degree Elbow Threaded Fittings / Screwed Fittings 1/8" NB to 4" NB in Class 2000LB, 3000LB & 6000LB ASME B16.11, BS3799
Incoloy 45 Degree Elbow
Incoloy Cross
Incoloy Tee
Incoloy Cross
Incoloy Coupling
Incoloy Half Coupling
Incoloy Cap
Incoloy Welding Boss
Forms of Forged Fittings Type of Forged Fittings Size Range Dimension Standards
Incoloy Buttweld Outlet(O’Let) — BW/SW/NPT Outlets 1/2” to 14” MSS SP97
Incoloy Elbow Outlet — BW/SW/NPT
Incoloy Lateral Outlet — BW/SW/NPT
Incoloy Nipple Outlet — BW/SW/NPT
Incoloy Flange Buttweld Outlet
Incoloy Flange Nipple Outlet

Forms of ASTM B564 UNS N08825 in Stock

In Stock Socket Weld Elbow Fittings

Socket Weld Elbow

Incoloy 825 Socket Weld Elbow Available ASTM B564 Fittings

In Stock Threaded Elbow Fittings

Threaded Elbow

Incoloy 825 Threaded Elbow Available in 1/8” to 4”, 2000LB, 3000LB & 6000LB

In Stock Socket Weld Tee Forged Fittings

Socket Weld Tee

Incoloy 825 Socket Weld Tee Available In 1/8” to 4”, 3000LB & 6000LB

In Stock Threaded Tee Forged Fittings

Threaded Tee

Incoloy 825 Tee ASTM B564 in size 1/8” to 4”, 2000LB, 3000LB & 6000LB

In Stock Socket Weld Cross Forged Fittings

Socket Weld Cross

ASTM B564 Incoloy 825 Socket Weld Cross Available In 1/8” to 4”, 3000LB & 6000LB

In Stock Threaded Cross Forged Fittings

Threaded Cross

Incoloy 825 Threaded Cross Available in 1/8” to 4”, 2000LB, 3000LB & 6000LB

In Stock Forged Fitting - Socket Weld Coupling

Socket Weld Coupling

Incoloy 825 Socket Weld Coupling Available In 1/8” to 4”, 3000LB & 6000LB

In Stock Forged Fitting - Threaded Coupling

Threaded Coupling

Incoloy 825 Threaded Coupling Available in 1/8” to 4”, 2000LB, 3000LB & 6000LB

In Stock Forged Fitting - Socket Weld Cap

Socket Weld Cap

Incoloy 825 Cap ASTM B564 In Size 1/8” to 4”, 3000LB & 6000LB

In Stock Forged Fitting - Threaded Cap

Threaded Cap

Incoloy 825 Threaded Cap Available in 1/8” to 4”, 2000LB, 3000LB & 6000LB

In Stock Forged Fitting - Socket Weld Plug

Socket Weld Plug

ASTM B564 Fittings — Socket Weld Plug Available In 1/8” to 4”, 3000LB & 6000LB

In Stock Forged Fitting - Threaded Plug

Threaded Plug

Incoloy 825 Threaded Plug Available in 1/8” to 4”, 2000LB, 3000LB & 6000LB

In Stock Forged Fitting - Socket Weld Bushing

Socket Weld Bushing

Incoloy 825 Socket Weld Bushing Available In 1/8” to 4”, 3000LB & 6000LB

In Stock Forged Fitting - Threaded Bushing

Threaded Bushing

Incoloy 825 Threaded Bushing Available in 1/8” to 4”, 2000LB, 3000LB & 6000LB

In Stock Forged Fitting - Socket Weld Hex Nipple

Socket Weld Hex Nipple

Incoloy 825 Socket Weld Hex Nipple Available In 1/8” to 4”, 3000LB & 6000LB

In Stock Forged Fitting - Threaded Hex Nipple

Threaded Hex Nipple

Incoloy 825 Threaded Hex Nipple Available in 1/8” to 4”, 2000LB, 3000LB & 6000LB

In Stock Forged Fitting - Socket Weld Boss

Socket Weld Boss

Incoloy 825 Socket Weld Boss Available In 1/8” to 4”, 3000LB & 6000LB

In Stock Forged Fitting - Threaded Boss

Threaded Boss

Incoloy 825 Threaded Boss Available In 1/8” to 4”, 3000LB & 6000LB

In Stock Forged Fitting - Socket Weld Union

Socket Weld Union

Incoloy 825 Socket Weld Union Available In 1/8” to 4”, 3000LB & 6000LB

In Stock Forged Fitting - Threaded Union

Threaded Union

Incoloy 825 Threaded Union Available in ASTM B564 UNS N08825

  • Chemical Properties
  • Mechanical Properties
  • Physical Properties
  • C Ti Mn Fe S Si Cr Ni Cu Mo Al
    MIN - 0.600 - 22.000 - - 19.500 38.000 1.500 2.500 -
    MAX 0.050 1.200 1.000 - 0.030 0.500 23.500 46.000 3.000 3.500 0.200
  • Yield Strength
    0.2% Proof
    (MPa)
    Tensile strength
    (MPa)
    Elongation
    (% in 50mm)
    Hardness
    (HBW)
    MIN 241 586 30.00
    MAX       237
  • Density lb/in³ 0.294
    Mg/m³ 8.14
    Specific Heat Btu/lb•°F 0.105
    J/kg•°C 440
    Melting Range °F 2500-2550
    °C 1370-1400
    Curie Temperature °F <-320
    °C <-196
    Permeability 200 oersted (15.9 kA/m) 1.005

Properties of Incoloy 825 alloy

Incoloy 825 Cold Forming

Cold-forming properties and practices are essentially the same for Incoloy alloy 825 as for Inconel alloy 600. Although work-hardening rate is somewhat less than for the common grades of austenitic stainless steels, it is still relatively high. Forming equipment should be well powered and strongly built to compensate for the increase in yield strength with plastic deformation.

Incoloy 825 Hot Forming

The hot-working range for Incoloy alloy 825 is 1600 to 2150°F (870 to 1180°C). For optimum corrosion resistance, final hot working should be done at temperatures between 1600 and 1800°F (870 and 980°C). Cooling after hot working should be air cool or faster. Heavy sections may become sensitized during cooling from the hot-working temperature, and therefore be subject to intergranular corrosion in certain media. A stabilizing anneal restores resistance to corrosion. If material is to be welded or subjected to further thermal treatment and subsequently exposed to an environment that may cause intergranular corrosion, the stabilizing anneal should be performed regardless of cooling rate from the hot-working temperature.

Incoloy 825 Machining

All standard machining operations are readily performed on Incoloy alloy 825. The alloy normally has optimum machining characteristics in the annealed temper.

Incoloy 825 Welding

Incoloy alloy 825 has good weldability by all conventional processes. For most applications, Inconel Welding Electrode 112 for shielded metal-arc welding and Inconel Filler Metal 625 for gas-shielded processes are used. For applications that require highest resistance to corrosion, Inco-weld Welding Electrode 686CPT and Inco-weld Filler Metal 686CPT are used.

Incoloy 825 Heat Treatment

Incoloy 825 is stabilise annealed at 940°C. The softest structure is obtained at 980°C. Sections heavier than sheet, strip and wire should be quenched to avoid sensitisation.

Services We Offer

Documentation

Documentation is a very important part of the products we supply, and we work continuously to enhance the efficiency of the document-handling process without compromising quality of the product. Documents provided along with the shipment include Certificate of Origin, Material Test Certificate as per EN 10204 3.1 and 10204 3.2, NACE MR10103 and NACE MR0175 certified Test Certificates.

Quality Assurance

Incoloy Fittings and Forgings are manufactured and controlled to international standards such as ASTM, ASME, BS, MSS, EN, DIN or WERKSTOFFE. Our products undergo stringent quality tests before they are dispatched.

Material Testing

PMI Testing, Ultrasonic Test, Mechanical Testing, Spectro Tests for Chemical Analysis of the grade, Flaring Test, IGC, etc. are some of the tests conducted at our facility. We welcome stage wise inspection from any of your representative or third party inspection agencies.

Packing and Delivery

The product is wrapped and packed in wooden crates or carton boxes. Our primary goal is to deliver quality products in time, no matter where the client is located.
